DEC697 – OPNsense® Desktop Security Appliance

Description

A great performer with AMD G-Series SOC  performance in a very small fanless enclosure.
This model includes 8GB DDR3 RAM, 256GB NVMe Solid State Flash and can handle upto 5000Mbps Firewall & 600Mbps IPsec throughput .

Package Contents

• Desktop appliance
• Matching powercord
• Power supply
• Configuration cable
• Quickstart guide

Warranty

All OPNsense® Security Appliances come with 2 Year Carry-in & Return Warranty.

Full Specifications & Model Comparison

Models	DEC677	DEC697
Software
Preinstalled software	OPNsense®	OPNsense®
License	Open Source + 1 year free Business Edition	Open Source + 1 year free Business Edition
Hardware Specifications
Typical Applications	Firewall / Routing & VPN	Firewall / Routing, VPN, IDPS & Webproxy
2.5 GbE RJ45 Ports [ 100/1000/2500Mbps ]	4	4
USB Ports	1	1
Console Port	1	1
Internal Storage	32GB Solid State Flash [integrated uSD]	256GB NVMe Solid State Flash
Memory	4GB DDR3	8GB DDR3
CPU Cores	4 (max frequency 1.8Ghz)	4 (max frequency 1.8Ghz)
Virtual Interfaces (802.1q VLANS)1	4093	4093
System Performance
Firewall Throughput	5000Mbps	35000Mbps
Firewall Packets Per Second	420Kpps	420Kpps
Firewall Port to Port Throughput	2.3Gbps	2.3Gbps
Firewall Port to Port Packets Per Second	195Kpps	195Kpps
Concurrent Sessions	3000000	7000000
Connections Per Second	35000	35000
Firewall Latency (RTT)	125us	125us
Firewall Policies (Recommended Maximum)1	10000	10000
IPsec VPN Throughput (AES256GCM16)	600Mbps	600Mbps
IPsec VPN Packet Per Second (AES256GCM16)	50Kpps	50Kpps
Threat Protection Throughput Packet Per Second	N/A	50Kpps
Threat Protection Throughput	N/A	~541Mbps
High Availability with State Synchronisation	Requires Two	Requires Two
Dimensions
Height x Width x Length (mm)	22 x 185 x 134	22 x 185 x 134
Height x Width x Length (inches)	0.9 x 7.55 x 5.47	0.9 x 7.55 x 5.47
Form Factor	Desktop	Desktop
Weight (appliance only)	0.56 Kg	0.6 Kg
Weight (appliance + power supply / ac cord)	0.86 Kg	0.9Kg
Environment
Power Requirements	100-240VAC, 50-60Hz	100-240VAC, 50-60Hz
Maximum Current (AC)	0.4A	0.4A
Power Consumption (Typical)	13W	13W
Heat Dissipation	44 BTU/hr	44 BTU/hr
Operating Temperature	0 to +40°C	0 to +40°C
Storage Temperature	-20 to +70°C	-20 to +70°C
Humidity	10-90% non-condensing	10-90% non-condensing
Regulatory Compliance
	FCC part 15 Class A, CE, Rohs	FCC part 15 Class A, CE, Rohs

¹ The user interface is designed for normal business usage, large rulesets, high number of users or interface assignments may be less practical.

All measurements are based upon TCP traffic unless stated otherwise. Maximum PPS is a peak performance, measured using 500 byte packets.Firewall Port to Port package per seconds is the peak performance when using 1500 byte sized packages. Total Firewall Throughput is calculated by multiplying the maximum packets per second with a standard package size of 1500bytes. IPS performance is measured with aproximately 35000 rules enabled. IPsec VPN is measured using AES256GCM16+SHA512. Concurrent sessions are based upon memory available, where one state consumes 1KB of memory and 1GB of memory is reserved for system tasks. Latency is measured using netperf.
